Lattice Sentry Demo Board for MachXO3D

A complete platform to help you develop and test a NIST 800-193-compliant PFR solution. Includes numerous features to enable debug, interface and expansion

MachXO3D

Soft Processor, SPI Flash, Raspberry Pi, Security, Lattice Sentry, UAVs

Demo

Driver Monitoring System (DMS) Demonstration

The Driver Monitoring System Solution Demonstration highlights the capabilities of the newly introduced features of the Lattice Drive Solution Stack.

Avant-E, CertusPro-NX, CrossLink-NX

DMS, Raspberry Pi, Lattice Drive

Board

Space Development Board by Adiuvo

Developed by a team of experienced engineers for space and with prototyping space applications in mind, the board provides access to the commercial equivalent of the space grade Certus™-NX-RT, making it ideal for prototyping and test campaigns to increase the Technology Readiness Level.

Certus-NX

Community Sourced, Raspberry Pi, SpaceWire, Defense

Reference Design

SSPI Embedded Programming using RPi Reference Design

SSPI Embedded Programming reference design provides several benefits, such as low power consumption and reasonable CPU, GPU, and memory performance.

CertusPro-NX, CrossLink-NX, CrossLinkPlus, CrossLink, MachXO3, MachXO2

SSPI, Raspberry Pi

Board

Lattice Sentry Demo Board for Mach-NX

A complete platform to help you develop and test a NIST 800-193-compliant PFR solution. Includes numerous features to enable debug, interface and expansion

Mach-NX, ECP5 / ECP5-5G

UAVs, Defense, Soft Processor, SPI Flash, Raspberry Pi, Security, Lattice Sentry

Board

CrossLink-NX Evaluation Board

For general evaluation and development with CrossLink-NX, includes many flexible interfaces such as FMC and PMOD with generous device IO access

CrossLink-NX

Arduino, Breakout, FMC, PMOD, Raspberry Pi, SMA, SPI Flash, CSI-2, AR / VR & Drones, Home Control Appliances & Security, IoT & Wearables, Notebooks & PCs, Printers, Smart Toys & Robots, Tablets, Defense, Automotive

Board

ECP5 Evaluation Board

Evaluation and development for ECP5-5G FPGA - 85K LUTs. Includes generous IO access and easy expansion to PMOD, Arduino, RaspberryPI, SERDES interface and more

ECP5 / ECP5-5G

Arduino, Breakout, PMOD, Raspberry Pi, SERDES, Versa Connector, TOR Switch, AR / VR & Drones, Defense

Board

CertusPro-NX Evaluation Board

CertusPro-NX Evaluation Board, a FPGA-based rapid prototyping and testing of specific designs with the features of CertusPro-NX FPGA family.

CertusPro-NX

Breakout, SMA, SPI Flash, Raspberry Pi, FMC, SERDES, PMOD, Automotive, SDR

Board

Future Electronics Hedgehog Development Board

Future Electronics MachXO5-NX breakout board featuring LFMXO5-25-7BBG256C FPGA. Raspberry Pi, Arduino, MikroBus, PMOD, and MIPI camera/display interfaces.

MachXO5-NX

Breakout, PMOD, Arduino, Raspberry Pi, Embedded FPGA Flash, HyperRAM, I2C, SPI, CSI-2, DSI

Board

MachXO3D Development Board

General purpose evaluation and development for MachXO3D with generous IO access and multiple expansion connectors RaspberryPi, Arduino, Lattice Versa, and more.

MachXO3D

Arduino, Breakout, Raspberry Pi, Security, Hirose FX12, Versa Connector, TOR Switch

Board

IceZero

Low-cost general purpose platform for the RaspberryPi with 4 MBit SRAM and four 2 x 6 PMOD interfaces for 32 3.3V LVCMOS IOs. Powered/configured over the 2 x 20 Raspberry Pi header.

iCE40 LP/HX

Raspberry Pi, SRAM, HyperRAM, PMOD, Breakout

Board

icoBoard

Pin-compatible with Raspberry Pi 2 - B. Contains an 8K LUT, 100 MHz Lattice FPGA, 8 MBit of SRAM. Programmable in Verilog by a complete open source FPGA toolchain.

iCE40 LP/HX

Raspberry Pi, PMOD, SRAM, SPI Flash, HyperRAM, Breakout

Board

Pico-Ice

The Pico-Ice is a small, low-cost board with the Raspberry Pi Pico processor (RP2040) and a Lattice Semiconductor iCE40UP5K FPGA.​

iCE40 UltraPlus

Lattice sensAI, ARM, Soft Processor, PMOD, PWM, LED Control, Raspberry Pi, NOR Flash, SPI Flash, SRAM, USB Type-C

Reference Design

Basic ECP5 Dev Board by Matt Venn

This is a basic ECP5 evaluation board, with a Raspberry Pi - compatible header. Source files and test patterns are available at github.

ECP5 / ECP5-5G

Community Sourced, PMOD, Raspberry Pi, Breakout

Reference Design

BlackIce-II by myStorm

This board has been prototyped, and is available as a Reference Design on GitHub and other open-source community forums. It has an on-board Arm Cortex M4 microcontroller and features PMOD, Arduino and RPi expansion headers.

iCE40 LP/HX

Community Sourced, Arduino, PMOD, Raspberry Pi, SD Memory, Microcontroller

Board

MachXO3-9400 Development Board

General purpose evaluation and development for MachXO3, supporting hardware management demos with Lattice ASC plus Raspberry Pi and Arduino board connectors

MachXO3, Platform Manager 2 & L-ASC10

Arduino, Breakout, Mixed-Signal, Raspberry Pi, Versa Connector, TOR Switch

Board

Raspberry Pi FPGA add on board from Bugblat

Expand your Raspberry Pi capabilities with this add-on board from Bugblat featuring the MachXO2 FPGA. Version 2 now available

MachXO2

Breakout, Raspberry Pi

Board

CrossLink: LIF-MD6000 Raspberry Pi Boards

Connects to LIF-MD6000 Master Link board, for interface and development with RaspberryPi boards and cameras.

CrossLink

Hirose FX12, Raspberry Pi, Automotive
