The Lattice Mach-N2 family of small, secure control FPGAs delivers up to 220k System Logic Cells of density with integrated non-volatile flash, and offers small package options. Built using the Lattice Nexus 2 platform, the family is optimized for low power relative to the competition and delivers best-in-class device security with CNSA 2.0-compliant, post-quantum-ready protection in its class.
Integrated Security – PUF, user run-time security, and CNSA 2.0-compliant, post-quantum cryptography with crypto agility on the Root-of-Trust device.
Integrated Flash and Instant-on – On-chip non-volatile flash for configuration and data storage, protecting the bitstream from physical access and enabling single-chip boot in under 30 ms.
Low Power – Built on the low power Lattice Nexus 2 platform.
Features
- Features up to 220k System Logic Cells, 12 Mb embedded memory, and 520 – 18 x 18 multipliers
- Integrated non-volatile flash for secure configuration and data storage, with single-chip instant-on boot
- Hardware Root of Trust with Physically Unclonable Function (PUF) for DICE and SPDM attestation, and post-quantum cryptography (RoT device)
- CNSA 2.0-compliant cryptography with crypto agility to adjust to evolving security standards
- Class leading bitstream encryption (AES-256-GCM) and authentication (ECDSA / RSA)
