Low Power, Small Footprint ideal for Portable Medical Devices

During the holiday period (Dec 24 – Jan 4), response times from our Global Support Team may be longer than usual.

Related Applications


Newsletter Subscription

Medical Imaging and diagnostics devices are expanding rapidly, with many more use cases addressed by convenient, low cost Portable Medical Devices. Lattice simplifies and expands Medical Device capabilities by offering these benefits:

  • Camera Processing
  • Display Interfacing and Processing
  • Low latency interconnect
  • Artificial Intelligence
  • Sensor Interfacing and Aggregation
  • Flexible I/O expansion options

Lattice FPGAs are optimized for Medical Devices, offering the following benefits:

  • Up to 75% lower power than similar FPGAs
  • Small form factors – from 4mm x 4mm
  • Optimized MIPI Sensor and Display Interfacing
  • Scalable Performance
  • Lattice Stacks: Lattice mVision and Lattice sensAI

Lattice solutions stacks provide ready-to-go flexible IP building blocks, reference designs and platforms to further speed development of products.
