AXI to PCIe Bridge IP Core

Powerful PCIe communication with host main memory or other PCIe endpoints

相关产品

The AXI to PCIe Bridge IP core is Smartlogic’s IP solution with industry standard memory mapped AXI Interfaces. The IP core translates AXI4 memory read or writes to PCI-Express Transaction Layer Packets (TLPs) and translates PCIe memory read and write requests to AXI4 transactions

Features

  • No PCI Express protocol know-how required : The user only transmits valid AXI4 packets with payload
  • Fast and easy integration into user software : The supplied Linux or Windows Kernel Mode device drivers with comprehensive user manuals are designed for fast and easy integration into the user software.
  • Reference designs included : A Radiant demo design and C application are included and can be used as starting point for new designs
  • Support included for 6 months : The included support allows users to get help from our technical support
  • AXI4 Slave interface to initiate data transfers AXI to PCIe
  • Up to 8 AXI 4 Masters interfaces to receive transfers from PCIe
  • Low logic footprint, fits into small devices
  • Based on Lattice PCIe Hard IP

Block Diagram

AXI-Bridge Block Diagram放大图片

Diagram

  • 1 S-AXI and up to 8 M-AXI interfaces
  • Asynchronous clock input for each interface

Ordering Information

This IP core can be shipped as source code or encrypted source code.You can download the product brief from https://www.smartlogic.de/en/produkt/axi-bridge-for-pcie-ip-core/
