HDMI 2.1 eARC Transmitter/Receiver

Enhanced Audio Return Channel Solutions for all Versions of HDMI

Future Compatibility – eARC is the only way to ensure that an audio device will be fully compatible with future HDMI 2.1 televisions

Simplify – eARC makes home theaters easy to use.

Improve Performance – Delivers all of HDMI’s high bitrate home theater audio formats, including Dolby Atmos and DTS:X.

Features

  • Lattice ICs are available for both televisions and audio devices
  • Solutions work with any existing HDMI transmitter or receiver IC and can be used with any version of HDMI
  • Supports both HDMI 2.1 eARC and HDMI 1.4 legacy ARC modes with automatic ARC fallback
  • eARC Data Channel functions are supported via I2C interface: Transmits HDMI 2.1 standard, bi-directional discovery and control signals within the eARC signal
  • 4mm x 4mm QFN package with 0.4mm pin pitch

Family Table

HDMI eARC ASSPs SiI9437 SiI9438
HDMI 2.1 eARC Input Output
HDMI 2.1 eARC Bi-directional Data Channel Yes Yes
HDMI 1.4 eARC Fall-back Yes Yes
SPDIF Output Input
8-ch I2S interface @ 192 KHz Output Input
Package 32-pin QFN 32-pin QFN
Pin Pitch 0.4 mm QFN 0.4 mm QFN
Package Size 4 x 4 mm 4 x 4 mm
Starter Kit CP9437 CP9438

Example Solutions

Enhanced Audio Return Channel (eARC)

  • eARC is an audio link that is self-discovering, self-configuring, and fully automatic which sends audio backwards in the HDMI cable, from the TV to an audio device.
  • Automatically works with any video source the television is displaying.
  • Is automatically detected and the TV speaker automatically mutes when eARC is engaged.

AVR/Sound Bar (receives eARC)

  • Block Diagram with Sil9347 eARC Receiver (32-pin QFN)
  • With eARC, audio transmission is reverse direction.
  • An HDMI Transmitter in the audio device receives audio over the two eARC pins.

Documentation

Quick Reference
TITLE NUMBER VERSION DATE FORMAT SIZE
SiI9437/SiI9438 ARC/Enhanced ARC Receiver and Transmitter
SiI-DB-02013 2.0 11/7/2017 PDF 738.1 KB
