FPSCs from Lattice: ORT82G5/42G5

Lattice Semiconductor has developed the industry's fastest device for high-speed serial backplane data transmission. The ORCA ORT82G5 is made up of backplane transceivers containing eight channels, each operating over a range from 600 Mbits/s to 3.7 Gbits/s, with a full duplex synchronous interface with built-in Clock and Data Recovery (CDR), along with more than 400K FPGA system gates.

The ORT42G5 is made up of backplane transceivers containing four channels, each operating over a range from 600 Mbits/s to 3.7 Gbits/s, along with more than 400K FPGA system gates.

Both the ORT42G5 and ORT82G5 FPSCs offer a clockless high-speed interface for interdevice communication on a board or across a backplane. The built- in clock recovery of the ORT82G5/ORT42G5 allows for higher system performance, easier-to-design clock domains in a multiboard system, and fewer signals on the backplane.

ORT42G5/ORT82G5 Products

Note: The ORT42G5 provides one quad SERDES channel.

Features

• High-speed SERDES with programmable serial data rates from 0.6 Gbits/s to 3.7 Gbits/s.
• Asynchronous operation per receive channel (separate PLL per channel)
• Provides a 10 Gbits/s backplane interface to switch fabric with protection

Some of the Intellectual Property Features include:

• Programmable logic provides a variety of yet-to-be standarized interface functions
• POS-PHY interface for 10 gbits/s SONET/SDH and OTN systems and some 10 Gbits/s Ethernet systems
• Ethernet MAC functions at 10/100 Mbits/s, 1 Gbits/s and 10 Gbits/s

• Provides the FC-0 and FC-1 layers of the FibreChannel FC-PH Specification in the Embedded ASIC Core, including:
  • 8b/10b encoders/decoders
  • Link Synchronization State Machine (to ANSI X3.230-1994, Clause 12)
• User has the ability to perform 1G or 2G FibreChannel on a single device, allowing a seamless upgrade path
• Ideal for Chip-to-Chip communications
• Bit Error Rate of less than 10^-12 across 6 inches of FR-4 backplane and 24 inches of coax cable.

Lattice Advantages:

• Lowest power of any programmable SERDES vendor - 225mW @ 3.125Gbps, per channel including pre-emphasis and 8b/10b endecs.

ORT82G5 Evaluation Boards

The ORT82G5 High-Speed SERDES Briefcase Board includes a number of features to help the user thoroughly evaluate the performance of the ORT82G5 device, or aid in the development of custom designs. The board features numerous I/O connections, SMA connectors for high-speed signaling, on-board clocks (external clocks can be provided), on-board power management, and more.

View the ORT82G5 High-Speed SERDES Briefcase Board webpage.

ORT42G5 Evaluation Boards

The Lattice ORT42G5 Evaluation Board provides an evaluation and development platform for the Lattice ORT42G5 device. This versatile board contains all the features you need to evaluate the ORT42G5 device, or aid in your development process.

View the ORT42G5 Evaluation Board webpage.
