  • Silicon Image:  Can we adjust TMDS swing level of the Tx output port 1 and 2?

    FAQ

    Silicon Image:  Can we adjust TMDS swing level of the Tx output port 1 and 2?

    User could not change it due to register limitation. User only have 3 bits to change swing setting in tx1 and tx2, that means only 0-7 is acceptable.
  • When using Lattice

    FAQ

    When using Lattice's HDMI/DVI Interface reference design, do I have to use a TMDS Level Shifter for the HDMI Transmitter interface?

    Both High-Definition Multimedia Interface (HDMI) and Digital Visual Interface (DVI) adopt Transition Minimized Differential Signaling (TMDS) technology to transmit and receive data and clock over four differential links. The TMDS electrical interface requires DC termination to 3.3V at…
  • HDMI Mezzanine Card Daughter card

    Board

    HDMI Mezzanine Card Daughter card

    No longer available - for reference only. For the LatticeECP3 Video Protocol Board + Two HDMI/DVI Input Paths + HDMI/DVI with TMDS level shifter...
  • LatticeECP3 Video Protocol Board

    Board

    LatticeECP3 Video Protocol Board

    No longer available - for reference only. Includes video interfaces for ECP3 FPGA to various video standards + SD/HD/3G-SDI, DisplayPort, 7:1 LVDS video
