Overview
The Tri-Speed Ethernet Media Access Controller (TSMAC) core can be configured to operate in either the Gigabit mode (1000Mbits/sec data rate) or the Fast Ethernet mode (10/100 Mbits/sec data rate). Operation in either Gigabit mode or Fast Ethernet mode is selected by setting an internal register bit.
The Tri-Speed Ethernet MAC transmits and receives data between a host processor and an Ethernet network. The main function of the Ethernet MAC is to ensure that the Media Access rules specified in the 802.3 IEEE standard are met while transmitting a frame of data over Ethernet. On the receiving side, the Ethernet MAC extracts the different components of a frame and transfers them to higher applications through the FIFO interface.

The data received from the G/MII interface is first buffered until sufficient data is available to be processed by the Receive MAC (Rx MAC). The Preamble and the Start of Frame Delimiter (SFD) information are then extracted from the incoming frame to determine the start of a valid frame. The Receive MAC checks the address of the received packet and validates whether the frame can be received before transferring it into the FIFO. Only valid frames are transferred into the FIFO. This feature has the following two benefits: the systems need not re-calculate the Frame Check Sequence (FCS) again when the frame is being transmitted, and it also keeps the receive MAC relatively simple. The Tri-Speed MAC, however, always calculates CRC to check whether the frame was received error-free.
On the transmit side, the Tx MAC is responsible for controlling access to the physical medium. The Tx MAC reads data from an external client Tx FIFO, formats this data into an Ethernet packet and passes it to the G/MII module. The Tx MAC reads data from the Tx Client FIFO when the client indicates a packet is available, and the Tx MAC is in its appropriate state. The Tx MAC pre-fixes the Preamble and the Start-of-Frame Delimiter information to the data and appends the Frame Check Sequence at the end of the data. In half-duplex operation, the Tx MAC stores the first 64 bytes of data from the external FIFO in an internal buffer, to be used in re-transmitting data on collisions. The SGMII Easy Connect configuration option adds pins and logic for seamless connection to the Lattice's Gigabit Ethernet PCS IP core.
Features
- Compliant to IEEE 802.3z standard
- Generic 8-bit host interface
- 8-bit wide internal data path
- Generic transmit and receive FIFO interface
- Full-duplex operation in 1G mode
- Full- and half-duplex operation in 10/100 mode
- Transmit and receive statistics vector
- Programmable Inter-Packet Gap (IPG)
- Multicast address filtering
- Selectable MAC operating options
- Classic Tri-Speed MAC with G/MII
- Gigabit MAC with GMII
- SGMII Easy Connect MAC with GMII, configurable option available on LatticeECP3™, LatticeECP2/M, and LatticeSC/M devices
- Supports
- Full-duplex control using PAUSE frames
- VLAN tagged frames
- Automatic re-transmission on collision
- Automatic padding of short frames
- Multicast and Broadcast frames
- Optional FCS transmission and reception
- Optional MII management interface module
- Jumbo frames up to 9600 bytes
Performance and Resource Utilization
Results for LatticeECP31
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1264 |
1841 |
1195 |
2 |
25 |
125 |
| No |
GbE |
1088 |
1523 |
1063 |
1 |
22 |
125 |
| No |
SGMII |
1272 |
1837 |
1175 |
2 |
4 |
125 |
| Yes |
Classic |
1419 |
2013 |
1347 |
2 |
27 |
125 |
| Yes |
GbE |
1244 |
1735 |
1215 |
1 |
24 |
125 |
| Yes |
SGMII |
1421 |
1987 |
1327 |
2 |
6 |
125 |
1. Performance and utilization characteristics are in Lattice ispLEVER 7.2 SP1 software and Synplify Pro 9.6L2, targeting a LFE3-95E-6FN484CES FPGA. When using this IP core in a different density, speed, or grade within the LatticeECP3 family or in a different software version, performance may vary.
Results for LatticeECP2M1
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1371 |
1951 |
1195 |
2 |
25 |
125 |
| No |
GbE |
1153 |
1586 |
1063 |
1 |
22 |
125 |
| No |
SGMII |
1361 |
1933 |
1175 |
2 |
4 |
125 |
| Yes |
Classic |
1521 |
2078 |
1347 |
2 |
27 |
125 |
| Yes |
GbE |
1339 |
1825 |
1215 |
1 |
24 |
125 |
| Yes |
SGMII |
1519 |
2078 |
1327 |
2 |
6 |
125 |
1. Performance and utilization characteristics are in Lattice ispLEVER 7.2 SP1 software and Synplify Pro 9.6L2, targeting a LFE2M35E-5F484CES device. When using this IP core in a different density, speed, or grade within the LatticeECP2M family or in a different software version, performance may vary.
Results for LatticeECP21
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1371
|
1951
|
1192 |
2 |
25 |
125 |
| No |
GbE |
1153 |
1586 |
1063 |
1 |
22 |
125 |
| Yes |
Classic |
1521 |
2078 |
1347 |
2 |
27 |
125 |
| Yes |
GbE |
1339 |
1825 |
1215 |
1 |
24 |
125 |
1. Performance and utilization characteristics are in Lattice ispLEVER 7.2 SP1 software and Synplify Pro 9.6L2, targeting a LFE2-20E-5F484CES device. When using this IP core in a different density, speed, or grade within the LatticeECP2 family or in a different software version, performance may vary. 2. The SGMII Easy Connect option is only available on device families with SERDES I/O.
Results for LatticeEC/P1
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1365
|
1936 |
1197 |
2
|
25
|
125 |
| No |
GbE |
1155 |
1597 |
1197 |
1 |
22 |
125 |
| Yes |
Classic |
1502 |
2048 |
1348 |
2 |
27 |
125 |
| Yes |
GbE |
1324 |
1783 |
1231 |
1 |
24 |
125 |
1. Performance and utilization characteristics are in Lattice ispLEVER® 7.2 SP1 software and Synplify® Pro 9.6L2, targeting a LFEC10E-5F484C device. When using this IP core in a different density, speed, or grade within the LatticeECP/EC family or in a different software version, performance may vary. 2. The SGMII Easy Connect option is only available on device families with SERDES I/O.
Results for LatticeSC/M1
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1367
|
1998 |
1198
|
2 |
25
|
125 |
| No |
GbE |
1104 |
1570 |
1064 |
1 |
22 |
125 |
| No |
SGMII |
1348 |
1971 |
1178 |
2 |
4 |
125 |
| Yes |
Classic |
1504 |
2177 |
1351 |
2 |
27 |
125 |
| Yes |
GbE |
1262 |
1774 |
1217 |
1 |
24 |
125 |
| Yes |
SGMII |
1493 |
2161 |
1331 |
2 |
6 |
125 |
1. Performance and utilization characteristics are in Lattice's ispLEVER 7.2 SP1 software and Synplify Pro 9.6L2, targeting a LFSC3GA15E-5F900CES device. When using this IP core in a different density, speed, or grade within the LatticeSC/M family or in a different software version, performance may vary.
Results for LatticeXP21
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1371
|
1951 |
1195
|
2 |
25
|
125 |
| No |
GbE |
1153 |
1586 |
1063 |
1 |
22 |
125 |
| Yes |
Classic |
1521 |
2078 |
1347 |
2 |
27 |
125 |
| Yes |
GbE |
1339 |
1825 |
1215 |
1 |
24 |
125 |
1. Performance and utilization characteristics are in Lattice ispLEVER 7.2 SP1 software and Synplify Pro 9.6L2, targeting a LFXP2-17E-6F484 device. When using this IP core in a different density, speed, or grade within the LatticeXP2 family or in a different software version, performance may vary. 2. The SGMII Easy Connect option is only available on device families with SERDES I/O.
Results for LatticeXP1
| Configuration |
SLICEs |
LUTs |
REGs |
EBRs |
External Pins |
fMAX (MHz) |
| MIIM Module |
Operation Mode2 |
| No |
Classic |
1365
|
1936 |
1197
|
2 |
25 |
125 |
| No |
GbE |
1155 |
1579 |
1079 |
1 |
22 |
125 |
| Yes |
Classic |
1502 |
2048 |
1348 |
2 |
27 |
125 |
| Yes |
GbE |
1324 |
1783 |
1231 |
1 |
24 |
125 |
1. Performance and utilization characteristics are in Lattice ispLEVER 7.2 SP1 software and Synplify Pro 9.6L2, targeting a LFXP10C-5F388CES device. When using this IP core in a different density, speed, or grade within the LatticeXP family or in a different software version, performance may vary. 2. The SGMII Easy Connect option is only available on device families with SERDES I/O.
Demo
A demo is available for the LatticeXP family and highlights the capability of the Tri-Speed Ethernet MAC IP core to function in a real network environment. For more information about this demo, please click here.
Ordering Information
The Tri-Speed Ethernet MAC is a user-configurable IP core, which allows the configuration of the IP and generation of a netlist and simulation file for use in designs. Please note that the FPGA programming bitstream will have time-out logic unless a license for the IP is purchased.
Part Numbers:
| LatticeECP3 |
TS-MAC-E3-U4 |
| LatticeECP2M |
TS-MAC-PM-U4 |
| LatticeECP2 |
TS-MAC-P2-U4 |
| LatticeECP/EC |
TS-MAC-E2-U4 |
| LatticeSC |
TS-MAC-SC-U4 |
| LatticeXP2 |
TS-MAC-X2-U4 |
| LatticeXP |
TS-MAC-XM-U4 |
For information about evaluating or purchasing the Tri-Speed Ethernet Media Access Controller IP Core, please contact your local Lattice Sales Office.
|
|
