Lattice ispGDX2 Devices - 38 Gbps ISP Switch with Advanced System Features


Lattice ispGDX2 - 38 Gbps Bandwidth, 800 Mbps SERDES The ispGDX2 family is Lattice's next generation in-system programmable (ISP) high performance digital crosspoint switch for high-speed bus switching and interfacing with bandwidth of up to 38Gbps. This family combines a flexible switching architecture with advanced high speed serial I/O (sysHSI blocks), sysCLOCK PLLs, and sysIO interfaces to meet the needs of today's high-speed systems. A multiplexer based architecture and on chip control logic facilitate the high performance implementation of common switching functions. Devices in the family can operate at 3.3, 2.5 & 1.8V core Voltage.

The ispGDX2 family is available in two options. The standard device supports SYSHSI availability for ultra fast serial communications and the "E-Series", a high performance, low-cost device with no sysHSI functionality.

Family Member Selector Guide
Vcc Device Registers PLLs Duplex
SERDES
Channels*
Speed
tPDFmax
I/Os Packaging
1.8 ispGDX2/E-64C 64 2 4 3.0 360 64 100-fpBGA
ispGDX2/E-128C 128 2 8 3.2 330 128 208-fpBGA
ispGDX2/E-256C 256 4 16 3.5 300 256 484-fpBGA
2.5 ispGDX2/E-64B 64 2 4 3.0 360 64 100-fpBGA
ispGDX2/E-128B 128 2 8 3.2 330 128 208-fpBGA
ispGDX2/E-256B 256 4 16 3.5 300 256 484-fpBGA
3.3 ispGDX2/E-64V 64 2 4 3.0 360 64 100-fpBGA
ispGDX2/E-128V 128 2 8 3.2 330 128 208-fpBGA
ispGDX2/E-256V 256 4 16 3.5 300 256 484-fpBGA
* "E-Series" does not support sysHSI.



Features

High Performance Bus Switching

  • High Bandwidth
    • Up to 12.8 Gbps (SERDES)
    • Up to 38 Gbps (without SERDES)
  • Up to 16 (15X10) FIFOs for data buffering
  • High-speed Performance
    • fMAX = 360 MHz, tPD = 3.0ns
    • tCO = 2.9ns , tS = 2.0ns
  • I/O intensive: 64 to 256 I/Os
  • Expanded MUX capability up to 188:1 MUX

sysCLOCK PLL

  • Frequency synthesis and skew management
  • Clock shifting, multiply and divide capability
  • Clock shifting up to +/-2.35ns in 335ps steps
  • Up to four PLLs

sysIO Interfacing

  • LVCMOS 1.8, 2.5, 3.3 and LVTTL support
  • SSTL 2/3 Class I and II support
  • HSTL Class I, III and IV support
  • GTL+, PCI-X support
  • LVPECL, LVDS and Bus LVDS support
  • Hot socketing
  • Programmable drive strength
  • sysHSI Blocks provide up to 16 High Speed Channels
    • Serializer/de-serializer (SERDES) included
    • Built-in Clock Data Recovery (CDR)
    • 800 Mbps per channel
    • LVDS differential support
    • 10B/12B support
      • Encoding / decoding
      • Bit alignment
      • Symbol alignment
    • 8B/10B support
      • Bit alignment
      • Symbol alignment
    • Source synchronous capability
  • Two options available
    • High performance sysHSI (Standard part number)
    • Low-cost, no sysHSI ("E-Series" part number)

Flexible Programming & Testing

  • 1.8/2.5/3.3V Power Supply Options
  • JTAG Boundary Scan Test & ISP

Architecture

The diagrams below shows the major blocks of the ispGDX2-64 device.

Click diagrams to view enlargements.

ispGDX2-64 Top Level Diagram small
ispGDX2-64 Top Level Diagram
sysCLOCK PLL small
sysCLOCK PLL

sysHSI small
sysHSI
GDX Block small
GDX Block

sysIO small
sysIO
MRB Block small
MRB Block
