The LatticeXP Standard Evaluation Board provides a stable yet flexible platform designed to help the user quickly evaluate the performance of the LatticeXP FPGA or aid in development of custom designs. For more advanced evaluation or development, see the LatticeXP Advanced Evaluation Board.
Product Contents
Each LatticeXP Standard Evaluation Board includes the following:
- LatticeXP Standard Evaluation Board featuring
- LFXP10C-4F256C or LFXP10E-4F256C
- On-board oscillator
- SMA pads for high-speed signals/clocks (SMA connectors not populated)
- Prototyping area
- Various LEDs for feedback
- ispDOWNLOAD Cable
- AC Adapter (international plugs)
Device Support
You will need the following software to use this board:
- ispLEVER for design, fitting, place & route of Lattice programmable devices
- ispVM to download your program to the Lattice XP device
Ordering Information
Part Number:
With LFXP10C-4F256C FPGA device: LFXP10C-L-EV
With LFXP10E-4F256C FPGA device: LFXP10E-L-EV
To purchase this board, please visit our Online Store. |
|
